WC26SMFD-32.768KHZ-T,WC26SM3044永利集团,MMD插件3044永利集团,圆柱3044永利集团,MMD音叉3044永利集团

频率：32.768 kHz

尺寸：3.45mm x 2.75mm

Manufacturer 品牌	WC26SMFD-32.768KHZ-T
Original model 原厂编码	MMD无源3044永利集团
Part Series 型号	WC26SM
Product Category 产品系列	kHz Crystal
Frequency 频率	32.768 kHz
Frequency Stability频率稳定性	-
frequency tolerance 频率容差	±20ppm
Load capacitance 负载电容	12.5pF
ESR (Equivalent Series Resistance)ESR（等效串联电阻）	50 kOhms
Operating Temperature温度	-40°C ~ 85°C
Size / Dimension尺寸	3.45mm x 2.75mm

订购热线：13380314981

WC26SMFD-32.768KHZ-T,WC26SM3044永利集团,MMD插件3044永利集团,圆柱3044永利集团,MMD音叉3044永利集团详细参数

Manufacturer 品牌	WC26SMFD-32.768KHZ-T
Original model 原厂编码	MMD圆柱3044永利集团
Part Series 型号	WC26SM
Product Category 产品系列	kHz Crystal
Frequency 频率	32.768 kHz
Frequency Stability频率稳定性	-
frequency tolerance 频率容差	±20ppm
Load capacitance 负载电容	12.5pF
ESR (Equivalent Series Resistance)ESR（等效串联电阻）	50 kOhms
Operating Temperature温度	-40°C ~ 85°C
Size / Dimension尺寸	3.45mm x 2.75mm
Termination 脚位	4 pad
Package Type 封装类型	4-SMD
Package Height 高度	0.75mm
Packaging 包装	Tape and Reel
Mounting Style 安装方式	Surface Mount

WC26SMFD-32.768KHZ-T,WC26SM3044永利集团,MMD插件3044永利集团,圆柱3044永利集团,MMD音叉3044永利集团相关产品

T10GC1-20.000MHZ-T	MMD	T	MHz Crystal	20 MHz晶体	±30ppm	±10ppm	10pF	80 Ohms
X10CB1-40.000MHZ-T	MMD	X	MHz Crystal	40 MHz	±30ppm	±15ppm	10pF	50 Ohms
X10CB1-30.000MHZ-T	MMD	X	MHz Crystal	30 MHz	±30ppm	±15ppm	10pF	50 Ohms
X10CB1-24.576MHZ-T	MMD	X	MHz Crystal	24.576 MHz	±30ppm	±15ppm	10pF	80 Ohms
X10CB1-22.1184MHZ-T	MMD	X	MHz Crystal	22.1184 MHz	±30ppm	±15ppm	10pF	80 Ohms
X10CB1-27.000MHZ-T	MMD	X	MHz Crystal	27 MHz	±30ppm	±15ppm	10pF	80 Ohms
X10CB1-32.000MHZ-T	MMD	X	MHz Crystal	32 MHz	±30ppm	±15ppm	10pF	50 Ohms
X10CB1-25.000MHZ-T	MMD	X	MHz Crystal	25 MHz	±30ppm	±15ppm	10pF	80 Ohms
DF18CC1-20.000MHZ-T	MMD	D	MHz Crystal	20 MHz	±30ppm	±15ppm	18pF	30 Ohms
DF18CC1-24.576MHZ-T	MMD	D	MHz Crystal	24.576 MHz	±30ppm	±15ppm	18pF	30 Ohms
DF18CC1-4.433619MHZ-T	MMD	D	MHz Crystal	4.433619 MHz	±30ppm	±15ppm	18pF	120 Ohms
DF18CC1-19.6608MHZ-T	MMD	D	MHz Crystal	19.6608 MHz	±30ppm	±15ppm	18pF	40 Ohms
DF18CC1-14.7456MHZ-T	MMD	D	MHz Crystal	14.7456 MHz	±30ppm	±15ppm	18pF	50 Ohms
DF18CC1-30.000MHZ-T	MMD	D	MHz Crystal	30 MHz	±30ppm	±15ppm	18pF	30 Ohms
DF18CC1-16.9344MHZ-T	MMD	D	MHz Crystal	16.9344 MHz	±30ppm	±15ppm	18pF	40 Ohms
DF18CC1-6.144MHZ-T	MMD	D	MHz Crystal	6.144 MHz	±30ppm	±15ppm	18pF	90 Ohms
DF18CC1-7.3728MHZ-T	MMD	D	MHz Crystal	7.3728 MHz	±30ppm	±15ppm	18pF	90 Ohms
DF18CC1-4.194304MHZ-T	MMD	D	MHz Crystal	4.194304 MHz	±30ppm	±15ppm	18pF	120 Ohms
DF18CC1-18.432MHZ-T	MMD	D	MHz Crystal	18.432 MHz	±30ppm	±15ppm	18pF	40 Ohms
DF18CC1-15.360MHZ-T	MMD	D	MHz Crystal	15.36 MHz	±30ppm	±15ppm	18pF	40 Ohms
DF18CC1-6.7458MHZ-T	MMD	D	MHz Crystal	6.7458 MHz	±30ppm	±15ppm	18pF	90 Ohms
DF18CC1-18.000MHZ-T	MMD	D	MHz Crystal	18 MHz	±30ppm	±15ppm	18pF	40 Ohms
DF18CC1-12.000MHZ-T	MMD	D	MHz Crystal	12 MHz	±30ppm	±15ppm	18pF	50 Ohms
DF18CC1-4.9152MHZ-T	MMD	D	MHz Crystal	4.9152 MHz	±30ppm	±15ppm	18pF	120 Ohms
DF18CC1-28.63636MHZ-T	MMD	D	MHz Crystal	28.63636 MHz	±30ppm	±15ppm	18pF	30 Ohms
DF18CC1-6.000MHZ-T	MMD	D	MHz Crystal	6 MHz	±30ppm	±15ppm	18pF	90 Ohms
DF18CC1-5.000MHZ-T	MMD	D	MHz Crystal	5 MHz	±30ppm	±15ppm	18pF	100 Ohms
DF18CC1-13.500MHZ-T	MMD	D	MHz Crystal	13.5 MHz	±30ppm	±15ppm	18pF	50 Ohms
DF18CC1-24.000MHZ-T	MMD	D	MHz Crystal	24 MHz	±30ppm	±15ppm	18pF	30 Ohms
DF18CC1-11.0592MHZ-T	MMD	D	MHz Crystal	11.0592 MHz	±30ppm	±15ppm	18pF	50 Ohms
DF18CC1-9.216MHZ-T	MMD	D	MHz Crystal	9.216 MHz	±30ppm	±15ppm	18pF	70 Ohms
DF18CC1-12.288MHZ-T	MMD	D	MHz Crystal	12.288 MHz	±30ppm	±15ppm	18pF	50 Ohms
T10GC1-22.1184MHZ-T	MMD	T	MHz Crystal	22.1184 MHz	±30ppm	±10ppm	10pF	80 Ohms
T10GC1-24.000MHZ-T	MMD	T	MHz Crystal	24 MHz	±30ppm	±10ppm	10pF	80 Ohms
T10GC1-19.200MHZ-T	MMD	T	MHz Crystal	19.2 MHz	±30ppm	±10ppm	10pF	100 Ohms
T10GC1-24.576MHZ-T	MMD	T	MHz Crystal	24.576 MHz	±30ppm	±10ppm	10pF	80 Ohms
T10GC1-16.000MHZ-T	MMD	T	MHz Crystal	16 MHz	±30ppm	±10ppm	10pF	100 Ohms
T10GC1-16.384MHZ-T	MMD	T	MHz Crystal	16.384 MHz	±30ppm	±10ppm	10pF	100 Ohms
T10GC1-48.000MHZ-T	MMD	T	MHz Crystal	48 MHz	±30ppm	±10ppm	10pF	50 Ohms
X10CB1-16.000MHZ-T	MMD	X	MHz Crystal	16 MHz	±30ppm	±15ppm	10pF	120 Ohms
X10CB1-16.3676MHZ-T	MMD	X	MHz Crystal	16.3676 MHz	±30ppm	±15ppm	10pF	120 Ohms
X10CB1-26.000MHZ-T	MMD	X	MHz Crystal	26 MHz	±30ppm	±15ppm	10pF	80 Ohms
X10CB1-24.000MHZ-T	MMD	X	MHz Crystal	24 MHz	±30ppm	±15ppm	10pF	80 Ohms
X10CB1-16.384MHZ-T	MMD	X	MHz Crystal	16.384 MHz	±30ppm	±15ppm	10pF	120 Ohms
WC26SMFD-32.768KHZ-T	MMD	WC26SM	kHz Crystal	32.768 kHz	-	±20ppm	12.5pF	50 kOhms
DF18CC1-8.000MHZ-T	MMD	D	MHz Crystal	8 MHz	±30ppm	±15ppm	18pF	70 Ohms
WC38F-32.768KHZ	MMD	WC	kHz Crystal	32.768 kHz	-	±20ppm	12.5pF	35 kOhms
WC26F-32.768KHZ	MMD	WC	kHz Crystal	32.768 kHz	-	±20ppm	12.5pF	35 kOhms
X10CB1-48.000MHZ-T	MMD	X	MHz Crystal	48 MHz	±30ppm	±15ppm	10pF	50 Ohms
X10CB1-20.000MHZ-T	MMD	X	MHz Crystal	20 MHz	±30ppm	±15ppm	10pF	80 Ohms
DF18CC1-25.000MHZ-T	MMD	D	MHz Crystal	25 MHz	±30ppm	±15ppm	18pF	30 Ohms
T10GC1-18.432MHZ-T	MMD	T	MHz Crystal	18.432 MHz	±30ppm	±10ppm	10pF	100 Ohms
X10CB1-19.200MHZ-T	MMD	X	MHz Crystal	19.2 MHz	±30ppm	±15ppm	10pF	120 Ohms
T10GC1-16.3676MHZ-T	MMD	T	MHz Crystal	16.3676 MHz	±30ppm	±10ppm	10pF	100 Ohms
X10CB1-18.432MHZ-T	MMD	X	MHz Crystal	18.432 MHz	±30ppm	±15ppm	10pF	120 Ohms
T10GC1-25.000MHZ-T	MMD	T	MHz Crystal	25 MHz	±30ppm	±10ppm	10pF	80 Ohms
T10GC1-27.000MHZ-T	MMD	T	MHz Crystal	27 MHz	±30ppm	±10ppm	10pF	80 Ohms
T10GC1-40.000MHZ-T	MMD	T	MHz Crystal	40 MHz	±30ppm	±10ppm	10pF	50 Ohms
T10GC1-30.000MHZ-T	MMD	T	MHz Crystal	30 MHz	±30ppm	±10ppm	10pF	50 Ohms
DF18CC1-27.000MHZ-T	MMD	D	MHz Crystal	27 MHz	±30ppm	±15ppm	18pF	30 Ohms
